Geometric Dimensioning and Tolerancing (GD & T)
Through our GDT courses, you'll learn to avoid confusion and miscommunication; increase robustness by knowing when to use geometric tolerance; reduce part rejection and scrap rates; and save money for you, your suppliers and your customers.
Duration
24 Hrs
Skill Level
Beginner
Materials Provided
Student GuideActivity material
Who Should Attend
SupervisorsInspectorsLead PeopleSet-up PeopleMachine operatorsEngineers (Refresher)CAD/CAM operators (Refresher)
Complete Curriculum
Full breakdown of all course topics
Objectives & Basic Overview
Comparison of the 'Old' Methods
GD&T Symbology
MMC, LMC and RFS
Form controls
Orientation controls
Composite controls
Location controls
Profile controls
Course Roadmap
01
Focus Topics
Detailed Breakdown for Day 1
Objectives & Basic Overview
Comparison of the 'Old' Methods
GD&T Symbology
Required Knowledge
None
